NeXuS Security Stack

Sane • Simple • Secure — Multi-layer intrusion detection and prevention.

Hydra Overseer — AppArmor as the hardened core, Psad · Tynis · Tiger · RKhunter · Tripwire as the enforcement heads.

Architecture Overview

Internet
   │
   ▼
[UFW firewall] — blocks + logs [UFW BLOCK] prefix
   │
   ▼
[klogd] — reads kernel ring buffer → syslogd → /var/log/messages
   │
   ├──► [PSAD] — port scan detection, danger levels 1-5, auto-block via iptables
   │       └──► [fwsnort] — Snort IDS rules translated to iptables (29,600+ signatures)
   │
   └──► [fail2ban] — brute-force detection, bans repeat offenders

---

PSAD — Port Scan Attack Detector

PSAD reads iptables/UFW logs and classifies port scans by danger level (1–5).

Prerequisites — Logging Chain

PSAD only sees what reaches syslog. The full chain must be intact:

1. UFW must log with the right prefix (/etc/ufw/before.rules):

   -A ufw-before-input -j LOG --log-prefix "[UFW BLOCK] " --log-level 4
   -A ufw-before-forward -j LOG --log-prefix "[UFW BLOCK] " --log-level 4


2. klogd must be running (reads kernel ring buffer → syslogd):

   doas rc-update add klogd boot
   doas rc-service klogd start


3. psad.conf must point at the right daemon and prefix (/etc/psad/psad.conf):

   SYSLOG_DAEMON           syslogd;
   IPT_SYSLOG_FILE         /var/log/messages;
   IPT_PREFIX              [UFW BLOCK];


Danger Levels

Level	Meaning	Action
1	Low-risk probe	Log only
2	Moderate scan	Log only
3	Active scan (>50 ports)	Email alert
4	Aggressive scan	Block + email
5	Full port sweep	Block + email + psadwatchd escalation

Daily Operations

# Check current status
doas psad --Status

# Show blocked IPs
doas psad --Status | grep "Danger level [3-5]"

# Flush all blocks
doas psad --flush-blocked-ip all

# Force signature reload after fwsnort update
doas psad -H

# Update signatures + reload
doas psad --sig-update && doas psad -H

# Live log watching
tail -f /var/log/psad/status.out

Config Reference (/etc/psad/psad.conf)

Key	Value	Notes
SYSLOG_DAEMON	syslogd	NOT metalog (even if metalog.conf exists)
IPT_SYSLOG_FILE	/var/log/messages	Where busybox syslogd writes
IPT_PREFIX	[UFW BLOCK]	Must match UFW log prefix exactly
ENABLE_AUTO_IDS	Y	Enable automatic blocking
AUTO_IDS_DANGER_LEVEL	3	Block at level 3+
EMAIL_ALERT_DANGER_LEVEL	3	Email at level 3+

---

fwsnort — Snort Rules → iptables

fwsnort translates Snort IDS signatures into iptables rules, giving PSAD application-layer awareness.

nftables Compatibility Fix

Alpine's iptables-nft (v1.8.11) rejects the old !port negation syntax. fwsnort generates ~8 rules with this pattern that must be stripped before applying.

Fix script (~/scripts/nexus-fix-fwsnort-nftables.sh):

#!/bin/sh
# Strip incompatible !port rules and apply the rest
sed -i '/dports.*,![0-9]/d; /sports.*,![0-9]/d' /var/lib/fwsnort/fwsnort_iptcmds.sh
IPTABLES=iptables sh /var/lib/fwsnort/fwsnort_iptcmds.sh
doas psad -H
echo "fwsnort rules applied"

Update Workflow

# Full update (downloads new rules, regenerates, applies, reloads PSAD)
doas sh ~/scripts/nexus-update-fwsnort.sh

# Manual steps:
doas fwsnort --update-rules   # download latest Snort community rules
doas fwsnort                  # translate to iptables
doas sh ~/scripts/nexus-fix-fwsnort-nftables.sh  # strip bad rules + apply
doas psad --sig-update && doas psad -H            # reload PSAD

Verify Rules Loaded

# Count fwsnort rules in iptables
doas iptables -L | grep -c FWSNORT

# Should show ~29,600+ rules

---

fail2ban — Brute Force Protection

fail2ban monitors auth logs and bans IPs that exceed threshold.

Alpine-Specific Config

Alpine uses busybox syslogd writing to /var/log/messages — NOT /var/log/auth.log or /var/log/sshd_log.

/etc/fail2ban/paths-overrides.local:

[DEFAULT]
sshd_log = /var/log/messages
syslog_authpriv = /var/log/messages

/etc/fail2ban/jail.d/alpine-ssh.conf:

[sshd]
enabled = true
port = ssh
filter = sshd
logpath = /var/log/messages
maxretry = 5
bantime = 3600
findtime = 600

[sshd-ddos]
enabled = true
port = ssh
filter = sshd-ddos
logpath = /var/log/messages
maxretry = 5
bantime = 3600

Operations

# Check status (requires doas — socket is root-only)
doas fail2ban-client status
doas fail2ban-client status sshd

# Unban an IP
doas fail2ban-client set sshd unbanip 1.2.3.4

# Test a filter against log
doas fail2ban-regex /var/log/messages /etc/fail2ban/filter.d/sshd.conf

# Restart after config changes
doas rc-service fail2ban restart

---

AppArmor (Pending Activation)

AppArmor is installed but NOT active — the kernel LSM list is missing it.

Current kernel LSMs: lockdown,capability,landlock,yama

To activate, add to /boot/extlinux.conf APPEND line:

lsm=landlock,yama,apparmor

Then reboot. Verify with:

cat /sys/kernel/security/lsm
aa-status

Planned profiles (complain mode first, then enforce): - tor — /usr/bin/tor - privoxy — /usr/sbin/privoxy - psad — /usr/sbin/psad - nginx — /usr/sbin/nginx

---

Port Knocking (Queued)

knockd — SSH access via sequence knock, zero open ports visible.

Planned sequence: Three UDP ports → triggers temporary iptables rule → SSH accessible for 10s.

Status: Not yet configured. Install: doas apk add knockd

---

Fix Scripts Reference

Script	Purpose	Run As
~/scripts/nexus-fix-psad-logging.sh	Fix full UFW→klogd→syslogd→PSAD chain	doas sh
~/scripts/nexus-fix-fwsnort-nftables.sh	Strip bad !port rules + apply fwsnort	doas sh
~/scripts/nexus-update-fwsnort.sh	Full fwsnort update + PSAD reload	doas sh
~/scripts/nexus-fix-fail2ban.sh	Fix fail2ban logpath for Alpine	doas sh

---

Security Checklist

[ ] klogd running:        rc-service klogd status
[ ] UFW log prefix set:   grep "UFW BLOCK" /etc/ufw/before.rules
[ ] PSAD scanning:        psad --Status | grep "Pkts"
[ ] fwsnort rules loaded: iptables -L | grep -c FWSNORT
[ ] fail2ban active:      doas fail2ban-client status
[ ] AppArmor:             PENDING (extlinux.conf change required)
[ ] Port knocking:        PENDING (knockd not installed)
